Gimbal Bellows

Name: Gimbal Bellows
Brand: Siddharth Industries
Price: 10000.0 INR
Availability: InStock

Price 10000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Gimbal Bellows Specification

Surface Treatment
Powder Coated

Material
Stainless Steel

Usage
Industrial

Technique
Casting

Size
Standard Sizes

Product Type
Gimbal Bellows

Color
Silver

Gimbal Bellows Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Month

Delivery Time
5-10 Days

About Gimbal Bellows

A Gimbal Expansion Bellow is a specialized type of metallic expansion joint designed to absorb angular movement in any plane, using a system of gimbal rings and hinges. These are typically used in high-pressure and high-temperature piping systems where controlled movement and stress reduction are critical.

Key Features of Gimbal Expansion Bellows

Feature	Description
Purpose	Accommodates angular rotation in multiple planes.
Design	Consists of a bellows element connected to two gimbal rings, which are supported by hinge assemblies.
Movement Type	Angular only (no axial or lateral unless combined with other units).
Use Case	Used in systems with complex thermal expansion paths or where pipe alignment must be maintained.
Pressure/Temp.	Suitable for high-pressure and high-temperature applications.

Typical Construction

Metallic Bellows: Usually stainless steel or Inconel.
Gimbal Rings: External rings connected to the bellows via hinge arms.
Hinges/Pins: Allow rotation and hold the internal pressure thrust.
End Connections: Flanged or welded.

Advantages

Absorbs angular deflection in two planes simultaneously.
Prevents pressure thrust from being transmitted to adjacent equipment or piping.
Maintains system stability and alignment.
Can be used in combination with other expansion joints (like hinged or tied units) for complex movement systems.

Common Applications
